Model

LPV-100-12

LPV-100-24

DC output voltage

12V

24V

Output voltage error

±1%

±1%

Rated output current

8.5A

4.5A

Output current rage

0-8.5A

0-4.5A

Wave and noise

80mVp-p

100mVp-p

Inlet stability

±0.5%

±0.5%

Load stability

±0.5%

±0.5%

DC output power

100W

100W

Efficiency

85%

86%

AC input voltage range

180-264VAC

Input current

1.2A/115V 0.55A/230V

AC impulse current

Cold-start current 13A/115V 26A/230V

Leakage current

<0.75mA/240VAC

Over load protection

105%~150% rated output power

Protection:Hiccup mode,recover automatically

Over voltage protection

13~16V

28~32V

Protection:Shut down output voltage

Short circuit protection

Protection:Hiccup mode

Temperature coefficient

±0.03%(050)

Setup rise hold up time

100ms,60ms/230VAC

Vibration

10~500Hz,2G 10min./1cycle,Period for 60min,Each axes

Withstand voltage

I/P-O/P:2.5KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

Isolation resistance

I/P-O/P:100M Ohms / 500VDC / 25 / 65% RH

Working temperature and humidity

-10+60,20%90%RH

Store temperature and humidity

-20+85,10%95RH

Overall dimension

222x130x65mm

Weight

1.2KG

Safety standards

Desgin refer to UL1012,EN60950-1,EN61347-1,EN-61347-2 approved

EMC

EN55015,EN55022,EN55024,EN61000-2,EN61000-3,EN61547
