ROSS EUROPA Leak Tight, Standard & Low Pressure, Vacuum; LT32DB27500W01
LT Series, 3 Station Solenoid Valve Manifold, Normally Closed, Port (In) G1/4", Port (Out) G1/4", 24 VDC; LT32DB27500W01 Leak Tight & Vacuum Applications...
Cena na upit
LT Series, 3 Station Solenoid Valve Manifold, Normally Closed, Port (In) G1/4", Port (Out) G1/4", 24 VDC; LT32DB27500W01
- Leak Tight & Vacuum Applications
- Positive Sealing
- Self-Cleaning and Dirt Tolerant
- Repeatability Over the Life of the Valve
- Self-Compensating for Wear
| Valve Type | Directional Control |
| Application | Leak Test |
| Actuation | Electrical |
| Function | 3/4 Single Solenoid |
| Default Position | Normally Closed |
| Return | Detented |
| Thread Type | G |
| Inlet Pipe Size | 1/4" |
| Outlet Pipe Size | 1/4" |
| Exhaust Pipe Size | 1/4" |
| Construction | Poppet |
| Mounting | Base Mount |
| Connection | EN 175301-803 Form C |
| Pilot Type | Internal/External |
| Avg Cv | 0.9 |
| Voltage | 24 VDC |
| Duty Rating | Continuous Duty |
| Power Consumption | 1.5 watts |
| Ambient Temperature | 40 to 120 F (4 to 50 C) |
| Media Temperature | 40 to 120 F (4 to 50 C) |
| Fluid Media | Filtered Air |
| Operating Pressure | 2 to 145 psig (.13 to 10 bar) |
| Pilot Supply Minimum | equal to or greater than inlet pressure |
| Length | 6.30 (159.9) |
| Length (mm) | 159.9 |
| Width | 2.33 in (59.2 mm) |
| Height | 4.65 in (118.1 mm) |
| Weight | 3.6 lb (1.7 kg) |
| Valve Body Material | Cast Aluminum |
| Poppet/Spool Material | Acetal & Stainless Steel |
| Seal Material | Buna-N |
-
ROSS Dale Series LT Valves A-Model Installation Instructions SS051 A Model
-
ROSS Dale Series CP CX LF LX Model-A Installation Instructions SS050 A Model
-
ROSS Dale Series CP CX LF LX Model-B Installation Instructions SS050 B Model
