Helmholz System module – Potential distributor 4 x DC 24 V + 4 x GND
The 4x DC 24 V + 4x GND potential distributor makes the 24 V DC supply and the GND connection from the power bus available on the front connector. Max. 8 A supply...
Trenutno nema na stanju
The 4x DC 24 V + 4x GND potential distributor makes the 24 V DC supply and the GND connection from the power bus available on the front connector.
- Max. 8 A supply load
- Powers outputs using the power bus
- A blue LED indicates the module's operating status
| General information | ||
|---|---|---|
| Order number | 600-720-0DH01 | |
| Article name | Potential distributor 4x DC 24 V + 4x GND | |
| Scope of delivery | Potential distributor 4x DC 24 V + 4x GND | |
| Dimensions (DxWxH) | 110 x 14 x 73 mm | |
| Weight | Approx. 75 g | |
| Current draw | ||
| External | Max. 0 mA | |
| Internal | Max. 22 mA | |
| Power dissipation | Max. 0.1 W | |
| Load | ||
| Per contact | 8 A | |
| Total load, 24 VDC | 8 A | |
| Total load, GND | 8 A | |
| Total load, AUX | 8 A | |
| Hot-swap capable | Yes | |
| Ambient conditions | ||
| Ambient temperature | 0 °C … +60 °C | |
| Transport and storage temperature | -20 °C … +80 °C | |
| Relative air humidity | 95 % r H without condensation | |
| Protection rating | IP 20 | |
| Certifications | CE, UL | |
| UL | ||
| Surrounding Air Temperature | 0 °C … +60°C | |
| Pollution degree | 2 | |
| CE | ||
| Noise immunity | DIN EN 61000-6-2 “EMC Immunity” | |
| Interference emission | DIN EN 61000-6-4 “EMC Emission” | |
| Vibration and shock resistance | DIN EN 60068-2-8:2008 “Vibration”, DIN EN 60068-27:2010 “Shock“ | |
| RoHS | Yes | |
| REACH | Yes | |
