Festo Proximity sensor SMTO-1-PS-S-LED-24-C ; 151685
Attachable magneto-inductive cylinder switch in block design. Measuring principle: magneto-resistive LED switching status indication Cable length 2.5 m...
Price on request
Attachable magneto-inductive cylinder switch in block design.
- Measuring principle: magneto-resistive
- LED switching status indication
- Cable length 2.5 m
- Type code
- SMTO
- Design
- Block design
- Symbol
- 00991153
- Certification
- RCM compliance mark
- CE marking (see declaration of conformity)
- As per EU EMC directive
- Note on materials
- Free of copper and PTFE
- Measuring principle
- Magneto-inductive
- Ambient temperature
- -25 °C ... 70 °C
- Switching output
- PNP
- Switching element function
- N/O contact
- Reproducibility of switching value
- +/- 0.1 mm
- On time
- ≤ 1 ms
- Switch-off time
- ≤ 1 ms
- Max. output current
- 200 mA
- Max. switching capacity DC
- 6 W
- Voltage drop
- ≤ 3 V
- Residual current
- ≤ 0.01 mA
- Short-circuit protection
- Pulsed
- Overload protection
- Available
- DC operating voltage range
- 10 V ... 30 V
- Reverse polarity protection
- for all electrical connections
- Electrical connection
-
Plug
3-pin
M8x1 - Connection outlet orientation
- Longitudinal
- Type of mounting
- With accessories
- Max. tightening torque
- 0.3 Nm
- Product weight
- 20 g
- Housing material
-
POM
PUR
PC
Steel
PET
Die-cast zinc - Switching status indication
- LED yellow
- Degree of protection
- IP67
-
SMX-1 ENUS
